Thermo King RV-580
Thermo King RV-580 – Transport Cooling System for Critical Cargo
The Thermo King RV-580 is a high-performance reefer unit engineered for medium to large refrigerated vehicles. Built with precision temperature control and robust compressor technology, this model is a trusted solution for industries requiring dependable cold-chain support.
Specially developed for both perishable goods and medical transport, the RV-580 delivers advanced performance, making it an ideal Thermo King refrigeration transport cooling system for pharmaceutical distributors, vaccine transportation, and high-value medical deliveries.
With its reliable and stable cooling operation, the RV-580 meets stringent cold-chain requirements, ensuring your cargo stays within safe temperature ranges even in extreme environments. Whether you’re in food logistics or Thermo King medical transport solutions, this model offers industry-grade reliability.
Key Features of the Thermo King RV Series
1. Greater Capacity and Higher Efficiency
- Enlarged condenser and evaporator coils for improved heat exchange
- Fast pre-cooling enables quicker cargo temperature control
- Enhanced cooling output ensures optimal protection for temperature-sensitive goods
2. Compact Design and Flexible Installation
- Lightweight system design ideal for mini trucks and light-duty vans
- Dual mounting options: roof-mounted or nose-mounted
- Patented structure (e.g., RV-380 patent no. ZL201530106353.5)
3. High Reliability for More Uptime
- Long-life (10,000+ hours) single-piece fans
- Proven Thermo King compressor ensures rugged durability
- Upgraded electrical control system enhances operational reliability
4. Ease of Use and Maintenance
- Simplified electric wiring for easier diagnostics
- Reduced refrigerant usage supports environmental standards
- Removable relay box improves servicing efficiency
| Specification | RV-580 |
|---|---|
| Application Range | Medium-to-large trucks (12–28m³ box volume) |
| Mounting Style | Roof-mounted / Optional nose-mounted |
| Cooling Capacity @ 0°C | 5,800 W |
| Cooling Capacity @ -20°C | 2,800 W |
| Temperature Range | -25°C to +30°C |
| Refrigerant | R-404A |
| Airflow | 1,800 m³/h |
| Power Supply | 12V / 24V DC |
| Current Draw (24VDC) | 28 A |
| Weight (Approx.) | 68 kg (full system) |
| Parameter | RV-200 | RV-300 | RV-380 | RV-580 | RV-580 Plus | RV-680 II | RV-780 II |
|---|---|---|---|---|---|---|---|
| Temperature Range | -25°C~+30°C | -25°C~+30°C | -25°C~+30°C | -25°C~+30°C | -25°C~+30°C | -25°C~+30°C | -25°C~+30°C |
| Refrigerant | R-404A | R-404A | R-404A | R-404A | R-404A | R-404A | R-404A |
| Cooling Capacity (0°C) (W) | 2,100 | 2,300 | 3,500 | 4,050 | 5,050 | 6,600 | 7,300 |
| Cooling Capacity (-20°C) (W) | 820 | 1,200 | 1,850 | 2,300 | 2,550 | 3,500 | 3,900 |
| Airflow (m³/h) | 700 | 1,500 | 1,500 | 2,500 | 2,500 | 2,500 | 3,000 |
| Power Consumption 24VDC (A) | 15 | 18 | 16.7 | 22 | 22 | 22 | 29 |
| Total Weight (Approx. kg) | ~42 | ~47 | ~54 | ~88 | ~92 | ~102 | ~103 |
